Product Introduction

Description

The DBFQ-HL1300 Computer-Controlled High-Speed Split-Type Slitting Machine is designed for precise, efficient, and high-speed slitting of various film and paper materials. It features an automatic shaftless unwinding system with pneumatic clamping and photoelectric edge alignment for stable feeding. The servo-driven traction unit ensures smooth and accurate material transmission, while the air knife slitting system delivers clean cuts with ±0.1mm precision and automatic blade positioning. Dual A/B-axis rewinding with Φ76mm slip shafts enables continuous operation, uniform tension, and automatic push-out for efficient roll handling. Controlled by a PLC system with a touch screen interface, the machine offers intelligent tension management and real-time monitoring. The integrated optical or ultrasonic EPC correction system provides ±75mm alignment accuracy, ensuring exceptional stability, reliability, and productivity for professional slitting operations.

Parameters

Model	DBFQ-HL1300
Slitting Speed	10–400 m/min
Maximum Material Width	200–1100 mm
Slitting Width	30–1100 mm
Slitting Material Thickness	12–600 μm
Slitting Accuracy	±0.1 mm
Maximum Unwinding Diameter	1200 mm
Maximum Rewinding Diameter	600 mm
Edge Alignment Method	Ultrasonic tracking
Tension Control Method	PLC control
Total Power	18 kW
Machine Weight	Approximately 5000 kg
Machine Dimensions (L×W×H)	2500 × 3700 × 2250 mm
Machine Color	Refer to the image above
Working Voltage	Three-phase 380V 50Hz

Feature

01.

1. Unwinding Unit

Function: This station unwinds the material roll to prepare it for further processing.
Key Features:
• Single station with pneumatic clamping ensures secure material holding.
• Automatic shaftless feeding enables convenient and efficient material loading.
• Photoelectric edge alignment keeps the material precisely aligned during unwinding.

02.

2. Traction & Transmission Unit

Function: This section controls material movement, feeding it through the machine with stable tension and speed.
Key Features:
• Servo motor drive provides accurate and smooth material feeding.
• Pneumatic clamping maintains stable tension for consistent operation.
• Rubber and chrome-plated steel rollers ensure steady traction without damaging the material surface.

03.

3. Slitting Unit

Function: This unit slits materials into the desired widths with high precision.
Key Features:
• Air knife slitting system provides clean and accurate cutting.
• Automatic blade positioning allows easy adjustments for various material widths.
• ±0.1mm slitting accuracy guarantees precise and consistent slitting results.

04.

4. Rewinding Unit

Function: This section rewinds slit materials into rolls and automatically ejects finished rolls from the machine.
Key Features:
• Alternating A/B axis rewinding ensures uninterrupted operation.
• Servo motor drive provides precise control of rewinding tension.
• Two Φ76mm slip shafts with key joints ensure smooth, uniform rewinding.
• Dual rewinding stations enhance productivity and efficiency.
• Maximum rewinding diameter: 600mm per roll.
• Equipped with 10 sets of infrared probes for accurate paper tube positioning.
• Automatic push-out mechanism moves finished rolls to the discharge arm after stopping.
• Discharge arm can unload up to 450kg of material, ensuring efficient handling.

05.

5. Control Section

Function: Manages machine operations to ensure precise, efficient performance.
Key Features:
• PLC centralized control system ensures stable and reliable operation.
• Touch screen interface provides intuitive parameter adjustments and easy monitoring.
• Automatic tension control maintains consistent tension during unwinding and rewinding.

06.

6. EPC Correction System

Function: Uses optical or ultrasonic sensors for accurate web alignment.
Key Features:
• Ensures precise material tracking and enhances cutting accuracy.
• ±75mm deviation range correction maintains optimal material positioning.
